1C Discharge Rate Lithium Iron Phosphate Battery Cells

1C Lithium Iron Phosphate (LiFePO4) Battery Solutions

BATFT 1C Lithium Iron Phosphate (LiFePO4) Pouch Cells

The 1C LiFePO4 Battery series by BATFT represents a high-performance rechargeable pouch cell solution engineered for longevity and stability. Every cell is the product of rigorous quality management overseen by the BATFT R&D and manufacturing divisions—encompassing stoichiometric material formulation, high-precision electrode coating, and advanced stacking technology. Each stage of production, including comprehensive end-of-line characterization, reflects our commitment to technical excellence and innovation.

Acclaimed for its superior charge/discharge dynamics and extended cycle life, this series has achieved widespread adoption across diverse sectors, including signaling & telecommunications, RC modeling, intelligent robotics, digital electronics, medical devices, and stationary energy storage systems (ESS). The lightweight, aluminum-plastic encapsulated architecture ensures ease of assembly and offers a versatile power integration solution for modern electronics.

分类：

Primary Application Fields BATFT’s self-developed LiFePO4 batteries are extensively utilized across diverse industrial and consumer sectors, providing robust power solutions for:

  • Emergency Systems: Jump starters and backup power supplies.

  • Energy Storage: Portable power stations and ESS.

  • Electric Mobility: Forklifts, go-karts, and high-performance racing ignition.

  • Robotics: Industrial automated guided vehicles (AGV/AMR).

  • Specialized Equipment: Sports medical devices and high-precision diagnostic tools. Our R&D team collaborates closely with clients to engineer bespoke power systems tailored to specific application requirements.

Technical Specifications: 1C LiFePO4 Series

Model C-Rate Nominal Voltage Capacity Max Cont. Current Dimensions (TWL) Weight (±g)
BATFT8218040 1C 3.2V 450mAh 0.45A 7.9 * 17.5 * 41.5 mm 10.0g
BATFT6230048 1C 3.2V 650mAh 0.65A 5.8 * 29.5 * 48.5 mm 15.0g
BATFT7830048 1C 3.2V 870mAh 0.87A 7.1 * 29.5 * 48.5 mm 19.5g
BATFT8329078 1C 3.2V 1600mAh 1.6A 8.0 * 28.0 * 76.5 mm 33.0g
BATFT8030085 1C 3.2V 1750mAh 1.75A 7.3 * 29.5 * 85.0 mm 36.5g
BATFT6543080 1C 3.2V 1850mAh 1.85A 6.0 * 42.5 * 79.5 mm 39.0g
BATFT8930085 1C 3.2V 2000mAh 2.0A 8.6 * 29.0 * 85.0 mm 42.0g
BATFT8041072 1C 3.2V 2050mAh 2.05A 7.4 * 40.5 * 73.0 mm 41.5g
BATFT8141072 1C 3.2V 2250mAh 2.25A 7.8 * 40.5 * 73.0 mm 45.0g
BATFT9041072 1C 3.2V 2300mAh 2.3A 8.2 * 40.5 * 72.5 mm 47.0g
BATFT5970096 1C 3.2V 2800mAh 2.8A 5.7 * 69.5 * 96.5 mm 70.5g
BATFT4163133 1C 3.2V 3000mAh 3.0A 3.9 * 63.0 * 132.5 mm 64.5g
BATFT5967105 1C 3.2V 3300mAh 3.3A 5.4 * 66.5 * 103.0 mm 70.0g
BATFT9549092 1C 3.2V 4000mAh 4.0A 9.2 * 48.5 * 92.0 mm 81.0g
BATFT6659134 1C 3.2V 4700mAh 4.7A 6.3 * 58.5 * 133.5 mm 99.0g
BATFT6865132 1C 3.2V 5000mAh 5.0A 6.5 * 62.5 * 129.5 mm 105.0g
BATFT8467100 1C 3.2V 5000mAh 5.0A 8.0 * 66.5 * 99.5 mm 104.5g
BATFT8074133 1C 3.2V 7500mAh 7.5A 7.7 * 73.5 * 133.0 mm 151.0g
BATFTA374115 1C 3.2V 8000mAh 8.0A 10.0 * 73.5 * 114.0 mm 162.0g
BATFT76B0136 1C 3.2V 10500mAh 10.5A 7.3 * 109.0 * 136.5 mm 219.0g
BATFTC488132 1C 3.2V 12500mAh 12.5A 12.1 * 87.0 * 131.0 mm 255.0g
BATFT93C0246 1C 3.2V 25000mAh 25.0A 9.0 * 119.0 * 245.0 mm 506.0g
BATFTA3C0246 1C 3.2V 30000mAh 30.0A 9.7 * 119.0 * 245.0 mm 570.0g

Key Technical Advantages

  • Inherent Safety: Superior chemical stability compared to other lithium chemistries; high resistance to thermal runaway, fire, and explosion.

  • Exceptional Cycle Life: Extended operational longevity with a rated lifecycle of 2,000 to 5,000 cycles.

  • Thermal Resilience: Reliable performance and structural integrity even in high-temperature environments.

  • Rapid Charging: Supports high-current charging protocols without compromising long-term battery health.

  • High Power Consistency: Delivers stable, high-power output for demanding industrial loads.

  • Lightweight Efficiency: Significantly reduced mass compared to lead-acid batteries of equivalent capacity, ideal for portable integration.

  • Eco-Friendly: Formulated with non-toxic, sustainable materials; features higher recyclability metrics.

  • Low Self-Discharge Rate: Maintains charge for extended periods during idle storage, ensuring “ready-to-use” reliability for backup systems.

  • Wide Operating Temperature: Exhibits consistent performance across extreme cryogenic and high-thermal conditions.

  • Linear Voltage Plateau: Maintains a flat discharge curve to ensure consistent device performance throughout the entire discharge cycle.

Why Partner with BATFT for LiFePO4 Solutions?

BATFT utilizes proprietary innovative technologies to maximize both power density and operational lifecycle. We offer a Turnkey Integration Service that combines: [Custom Cell Engineering + Intelligent BMS + Structural Pack Design] Our unique material formulations ensure high energy density, thermal resilience, and non-toxic safety. Partnering with BATFT grants you access to tailored energy solutions that enhance your product’s competitive edge.

  • Sustainability: Eco-friendly chemistry with higher recyclability.

  • Stability: Reliable performance under variable duty cycles.

  • Advanced Safety: Inherent chemical stability (Non-flammable).

  • High Burst Capability: Supports up to 25C instantaneous discharge.

  • Extreme Longevity: Rated for 2,000+ cycles.

  • Thermal Tolerance: Operational in environments up to 60°C.

  • Global Support: Localized technical assistance in China, USA, and Germany.

Professional Services Offered:

  • Flexible Customization for Specialized Missions

  • Reliable Mass Production Capabilities

  • Rapid Prototyping & Sampling

  • Comprehensive OEM & ODM Services
